Applications: Pligun ® HyREZIST® TS Mix

Apr 19, 2019

Applications: Pligun ® HyREZIST ® TS Mix



 Pligun® HyREZIST® TS Mix is a thermal shock resistant gunning material based around a fused silica/mullite matrix with a modified high cement bond.  This formulation allows for both good gunning characteristics and physical properties, as well as excellent thermal cycling resistance.  Maximum service limit for cycling is 2500°F while the optimum cycling performance range is 1500°F to 2300°F.



The product is advantageous in a number of ways:

  • Excellent thermal cycling resistance
  • Low thermal expansion
  • High fracture resistance: 1500°F to 2300°F
  • Good physical strength and abrasion resistance
  • No special gunning installation requirements

Have you heard of Pligun HyREZIST TS Mix? Learn the specs, best applications, and industries here! #TFL #TFLHouston
Click To Tweet


Specifications

  • Service Temperature Limit :  2500°F
  • Installation Method :  Gunning
  • Shelf Life : 9 months

Industries

  • Power Generation
  • Refining
  • Off Gas
  • Construction
  • Maintenance

Pro Tip: Pligun® HyREZIST® TS Mix is useful in a variety of industries including power generation, refining, construction, and more!

Applications

  • Wet Bottom ash hoppers
  • Incinerator and thermal oxidizer quench zones
  • Circulating Fluidized Bed (CFB) boilers – cyclones and downcomers
  • Alumina calciners
  • Aggregate and clay dryers and calciners
  • FCC units – seal pots and water spray ducts

Conclusion

TFL is a leading supplier of Plibrico castable and monolithic refractory materials including the Pligun® HyREZIST® TS MIX . Our refractory experts are dedicated to providing innovative solutions with the highest quality precast refractory shapes , refractories , and anchors . We also provide reliable turnkey services .

Would you like to learn more about the advantage of working with TFL? Chat with our refractory experts, today!
